CCM(Compact Camera Module)분야의 자동화 솔루션

Integrated Handler

Integrated Handler01
Integrated Handler02
Integrated Handler03
Integrated Handler04
Integrated Handler05
previous arrow
next arrow
SPECIFICATION
Loading Tray Height : 245mm
Target Device  Camera Module
Tray Zone Empty, Pass, Loading, Fail
Vision Top 1EA, Bottom 1EA
Barcode Reading Bottom Vision
System Weight Approximately 450kg
Power AC220V ± 10% (50/60Hz), 1 Phase, 1KW
Dry Air 5~7kgf/cm² Air 200 L/Min
Dimension 1350mm(L1) x 600mm(W1) x 1725mm(H1)
